PAE61 ball float air eliminator is designed to automatically discharge air/gas present in liquid systems without loss of liquid.
220 oC
16 bar(g)
CAST IRON
End connection: Screwed NPT / BSPT / BSP
| No. | PART | MATERIAL | QTY. |
|---|---|---|---|
| 1. | BODY | CAST IRON IS : 210 FG200 | 1 |
| 2. | COVER | CAST IRON IS : 210 FG200 | 1 |
| 3. | GASKET (COVER) | NON CAF | 1 |
| 4. | VALVE SEAT | AISI 410 / AISI 420 | 1 |
| 5. | VALVE | AISI 420 | 1 |
| 6. | LEVER | AISI 304 | 1 |
| 7. | FLOAT | AISI 304 | 1 |
| 8. | PLUG | AISI 304 | 1 |
| 9. | BOLT | HIGH TENSILE | 4 |
| 10. | DRAIN PLUG | C.S | 1 |
| 11. | GASKET DRAIN PLUG | COPPER | 1 |
| 12. | GASKET PLUG | COPPER | 1 |
| 13. | GASKET VALVE SEAT | COPPER | 1 |
| 14. | BRACKET ASSLY. | AISI 304 | 1 |
| SIZE | SCR/SW |
|---|---|
| DN15, 20 | 3.3 Kg |
